Main Features:
1. Refrigerant gas: R404A,R22,R507
2. Cooling type:water cooled
3. Overall diameter: 22mm, 29mm, 35mm
4. standard ambient : 30 °C, water temp: 25 °C
5. ice Cutter: Stainless steel ice cutter driven by gear motors are
uniquely designed to produce both cylindrical and crushed ice
simply by reversing the motor of the cutter using a switch on the
control panel that controls this function.
6. Tube ice making plant for the evaporator module and its
accessories are installed on a steel frame forms the evaporator
module. When transportation, place the evaporator horizontally and
upright it when installing. For big tube ice plant, we will send
engineer to your country to help with it.
Decription:
1. Water Distributor: Made up of elastic material which creates a
continuous uninterrupted peripheral seal between the tube ends and
water distributor.
2. Pumping Tank (Water Pump): Stainless steel Centrifugal pump with
large enough to circulate many times the quantity of water to be
frozen producing crystal clear ice crystals
3. Self-design, self-production, optimize every processing works,
make the machine a perfect performance.
4. Freezer: high quality stainless steel for all water and ice
contact surfaces providing corrosion resistance
Specification:
| Name | Technical Data |
| Ice production | 5ton/day |
| Refrigeration capacity | 33KW |
| Evaporating temp. | -15℃ |
| Condensing Temp. | 40℃ |
| Total Power | 23.75kw |
| Compressor Power | 20KW |
| Ice cutter Power | 0.75KW |
| Water pump Power | 0.75KW |
| Cooling tower power | 2.25KW |
| Net weight | 3310kg |
| Refrigerant gas | R404A/R22 |
| Cooling mode | water cooled |
| Standard Power | 3P-380V-50Hz |
| Ice tube diameter | Φ22mm/28mm/35mm |
| Ice length | 30 ~ 45MM |
| tube ice weight density | 500~550kg/m3 |
| Evaporator type | Stainless steel seamless steel pipe |
| Ice tube material | SUS304 stainless steel |
| Water tank material | SUS304 stainless steel |
| Ice cutting blade material | SUS304 stainless steel |
| Dimension of tube ice machine | 1900*1000*2080mm |
| |
Product Advantage:
1. Have CE(PED)ASME certificate, high indemnificatory
2. Beautiful shape, overall layout is reasonable, comprehensive
details, excellent.
3. The design of ice tube evaporator is according to pressure
vessel standard. It is strong , safe and reliable;
4. Full automatically control: PLC system controls the whole ice
making process, PLC program Logic Controller, which allows multiple
functions such as automatic machine start and shut down; ice
falling automatically when the freezing time is ensured, Automatic
water making up.
5. Sanitary
Quality and sanitary tube ice maker .All parts contacting with
water are made of stainless steel SUS304 or SUS316L and PE material
.
Product image:
FAQ:
1. What if I buy your ice machine, but I cannot find the solution
for the problem?
All ICESNOW ice plants come out with at least 12 months full
warranty. If the machine breaks down in 12 months, we will send the
parts for free, even send the technician over if situation needed.
When beyond the warranty, we will supply the parts and service only
for factory cost. Please provide the copy of Sales Contract and
describe the problems appeared.
2. Are you add refrigerant in the ice machine?
Yes, the machine is full of refrigerant, once with water and
electric it can work. yes, ice machine leaves factory with
carefully examination after it was produced for 3 to 5 days. And
when we install them at customer’s factory, we retest the ice
machines.
