Main Features:
1. Ice thickness: 1.8~2.2mm
2. The flake ice is glittering and translucent, hard and pure
3. The equipment can be used with stainless steel ice storage bins
or polyurethane ice storage bins, and a wide range of accessories
are available.
4. Ice blade: Made of SUS304 material seamless steel tube and
formed through only one time process. It's durable.
Decription:
1 . Advanced technology: Our flake ice machine evaporator uses
annealing heat treatment furnace and vibration aging process to
eliminate the welding stress. It can prevent the evaporator inner
wall from deformation and eventually prolong the evaporator working
life.
Flake ice Evaporator is made of imported SUS304 or carbon steel
with high heat transfer efficiency, whose surface is Nobelium
electroplated. The material can ensure the ice flake evaporator
excellent corrosion resistant and flake ice clean and hygiene.
2. Spindle and other accessories: made of SUS304 material through
precision machining, and conform to food hygiene standards.
3. Adopting the internally-scraping ice making mode, the ice blade
scraps ice within inner wall while the evaporator itself remains
not moving. It reduces the loss of energy as much as possible and
normally guarantees the supply of refrigerant as well as no
leaking.
4. All water supply line are made of stainless steel, high sanitary
condition;
Specification:
| Name | Technical Data |
| Ice production | 15Ton/day |
| Refrigeration capacity | 99KW |
| Evaporating temp. | -20℃ |
| Condensing Temp. | 40℃ |
| Ambient Temp. | 35℃ |
| Inlet water Temp. | 20℃ |
| Reducer motor Power | 0.75KW |
| Water pump Power | 0.37KW |
| Brine water Pump | 0.012KW |
| Standard Power | 380V/50Hz/3P,3P/220V/60Hz,380V/60Hz/3P |
| Inlet water pressure | 0.1Mpa－0.5Mpa |
| Refrigerant gas | R404A/R507/R22 |
| Flake ice Temp. | -5℃ |
| Feeding water tube size | 1/2" |
| Net weight | 1360kg |
| Dimension of flake ice evaporator | 2470*1680*1820.5mm |
Product Advantage:
1. Low failure and long working life: The system always runs well
more than 30000hours.
2. The evaporator with fixed vertical design is made of SUS304 or
carbon steel with high heat transfer efficiency and surface
Nobelium electroplated. And the automatic protection welding
equipment and annealing heat treatment furnace ensure the ice
machine high quality and better performance.
4. Perfect stability: In normal condition remains good output and
the special types run well in execrable conditions.
5. Energy-saving, place saving
6. Stable & reliable performance.
7. Energy-efficient & high-sufficiency for ice production
FQA:
Q1:What is the warranty for ice making machine?
A: 18 months after B/L date. Any failure occurred within this
period due to our responsibility, we'll supply you the spare parts
for free and permanent technical support &consultation all life
long for ice making machines.
Q2 : Can any of the products be custom imprinted?
A: If you need to print your company logo on the products and that
is available to be customized. Or if you have your own designed
idea and that will be our honor to customize for you.
Q3: Do I need to install the ice machine by myself?
A: For small ice machine, we ship it as a whole unit. So you just
need to prepare power and water to run the machine.
For some larger ice machine plant, we need to keep some components
separate for shipping convenience. But no worries about that. An
installation brochure will be sent to you,it's very to install the
machine.
Q4:When can I get the price?
A:Usually within 24 hours after we get your inquiry. And if you are
very urgent, you can call us or tell us by e-mail so we will
prioritize your inquiry.
Q5:How to confirm the quality before placing the order?
A:You are warmly welcomed to visit our factory and check the
quality.
