Main Features:
● Daily Capacity: 15ton/24hrs
● Machine power supply: 3P/380V/50HZ,3P/220V/60HZ,3P/380V/60HZ,
● PLC intelligent control system, fully automated production, no
manual operation required
● Adopt environmentally friendly refrigerant, environmental
protection, high efficiency and energy saving
● Refrigerant gas: R22/R404A/R507
Decription:
1 . Icesnow flake ice machine designed based on the features and
special requirements of supermarket freshing, lab and health care
industry, applicated to the field which demands high grade of ice
flake
2. Thermal insulation: foaming machine filling with imported
polyurethane foam insulation. Better effect.
3. PLC programmable control system -- The machine can start and
stop automatically to make the evaporator mechanical operation
system and water supplying circulation system coordination matched
and work safely & efficiently under the control of PLC controller.
The whole system is protected by the alarm of water shortage, ice
full, high and low pressure abnormal, power phase inverse and
compressor overload, etc.with the computer intelligence control.
When there is a failure, the PLC will stop the unit automatically
and the corresponding alarming indicator lights up. And when the
fault is settled, PLC controller will soon start the machine after
receiving the information. The whole system is controlled
automatically well without hand operation.
4. Flake Ice: Dry, pure, powder-less, not easy to block, its
thickness is about 1.8mm~2.2mm, without edges or corners which will
can product the cooling food, fish, seafood and other products.
Specification:
| Name | Technical Data |
| Ice production | 15ton/24h |
| Refrigeration capacity | 84502Kcal/h |
| Evaporating temp. | -20℃ |
| Condensing Temp. | 40℃ |
| Ambient Temp. | 35℃ |
| Inlet water Temp. | 20℃ |
| Total Power | 49.2kw |
| Compressor Power | 75HP |
| Reducer Power | 0.75KW |
| Water pump Power | 0.37KW |
| Brine Pump | 0.012KW |
| Standard Power | 3P-380V-50Hz |
| Inlet water pressure | 0.1Mpa－0.5Mpa |
| Refrigerant | R404A |
| Flake ice Temp. | -5℃ |
| Feeding water tube size | 1/2" |
| Net weight | 2650kg |
| Dimension of flake ice machine | 4440mm×2174mm×1951mm |
Product Advantage:
1. Scientific design and many years of engineering experience
Icesnow will offer you the best scheme of tailor-made ice-making
system We have not only supplied lots of ice flake systems to
customers from various places but also offered technological
consultancy to them.
2. High efficiency and energy saving
We have optimized the design of ice flake units to ensure the ice
flake units can function constantly without wasting energy. We have
also adopted a special kind of alloy material and patent processing
technology to ensure efficient heat conductivity.
3. Simple maintenance and convenient moving
All our equipment is designed on the basis of modules, so its spot
maintenance is quite simple. Once some of its parts needs
replacing, it is easy for you to remove the old parts and install
the new ones. Moreover while designing our equipment, we always
take into full account how to convenience future moves to other
construction sites.
4. Higher refrigeration efficiency and lower loss of refrigeration
capacity.
5. Scientific design and many years of engineering experience.
Product image:
Application:
FAQ:
1. Warranty:
1) 24 months warranty after delivery.
2)Professional after-sales department to provide 24/7 technical
support, all complaints should be replied within 24 hours.
3)Over 15 engineers available to service machinery overseas.
4)Free spare parts replacement within warranty period.
5)Beyond guarantee period, we will charge market price for spare
parts.
2. Why choose us ?
1) We have exported our ice machines to more than 150 countries ;
2)Excellent Brand of China Ice Machine Industry;
3)The Drafting Committee of National Ice Machine Industrial
Standard;
4)Produce & Academic Research Strategy Cooperating Partner with Tsing
Hua University.
